Dollar EXP140S Series 90kw Wet Extruder

The main power of this extruder is 90kw, the feeding power is 2.2kw, the conditioning power is 3kw, the cutting power is 2.2kw. It can produce 1.6-2.3 tons per hour. The machine weighs 2800kg.

Variable frequency speed control feeding: Precisely control the feeding amount, stabilize the extrusion effect, save energy and extend the equipment lifespan.

The conditioning unit is made of stainless steel laser plates: Through "the structural characteristics given by laser processing", it solves the core problems of the conditioning unit of the extruder from four aspects: "mixing, heat transfer, anti-sticking, and wear resistance", achieving a comprehensive upgrade of efficient, cost reduction, wide adaptability, and greater safety.

Quantitative water injection device: Precisely control the water injection amount to ensure that the material undergoes extrusion under the optimal moisture condition, improving the maturation degree, palatability and nutritional value of the feed.

Low oil/no oil automatic alarm: Real-time monitoring and timely warning to improve equipment safety, reliability and operational efficiency.

Imported sealing parts; shoulder double sealing: The shoulder double sealing technology, through the collaborative effect of two seals, can effectively prevent material leakage even when the extruder is running at high speed and the medium pressure fluctuates greatly, avoiding equipment contamination, raw material waste and deterioration of the production environment caused by leakage.

Lubricating oil circulation lubrication of the bearing box; circulating oil-water cooling device: This device provides stable working conditions for the bearing box through the "lubrication + cooling" collaborative effect, reducing equipment failure rate and improving the continuity of feed production.

The main shaft of the conditioning unit is equipped with adjustable conditioning conveying blades, allowing the material to undergo a pre-ripening process before entering the extrusion chamber, ensuring that the material and water (or water vapor) in the conditioning unit can be well mixed and conditioned;The parameters such as steam volume, feeding speed, mold hole size, etc. can be adjusted precisely to control the density, moisture content, and maturation degree of the finished product, ensuring stable product quality. Through steam conditioning (the core of the wet process), the feed raw materials are fully gelatinized, improving the nutritional digestibility, while also sterilizing, detoxifying, conditioning and improving the quality, avoiding cross-contamination throughout the process.

The wet process is because the raw materials are more easily extruded after steam pretreatment, the equipment operation is more stable, parameters can be adjusted according to different material types to meet diversified production needs, and is suitable for large-scale production.
